Chief's FUSION cart freestanding solution makes it possible to construct video walls in prominent locations for temporary situations.
Screen array configuration: 3 screens wide x 2 screens high in portrait
Features
Specifications
Center of Display to Floor/Table Range: | 24.47" (622 mm) (minimum bottom row) - 90.6" (2302 mm) (maximum top row) |
---|
Certifications: | UL Listed |
---|
Color: | Black |
---|
Lateral Shift: | Yes |
---|
Manual Height Adjustment: | Micro-adjustment up to 0.75" (19 mm) per screen |
---|
Mounting Pattern Compatibility (Universal Versions): | any width x 100 mm - 800 mm |
---|
Orientation: | Portrait |
---|
Overall Dimensions (H x W x D): | 106.7" x 68.0" x 40.4" (2710 x 1727 x 1026 mm) |
---|
Plumb Adjustment: | Micro-adjustment up to 0.75" (19 mm) |
---|
Screen Array Configuration: | 3 x 2 |
---|
Shipping Weight: | 269.00 lbs |
---|
Solution Type: | Universal |
---|
Typical Screen Sizes: | 42 - 46" (Larger displays possible with FCAX brackets, use MountFinder to confirm compatibility) |
---|
Weight Capacity: | 100 lbs. (45.4 kg) per screen |
---|
